MT-800 Motrec
| 80V | |
|---|---|
| Powertrain | |
| Motor | 40 hp AC motor |
| Drive Axle | Dual planetary wheel drives |
| Transmission | Integrated motor/axle, direct drive |
| Controller | Electronic speed controller, Inching controls on rear |
| Energy | |
| Voltage | 80V |
| Battery | No battery included |
| Charger | No charger included |
| Chassis | |
| Body | All-steel unibody construction |
| Suspension | Front leaf spring suspension with dual shock absorbers, rear rubber spring suspension |
| Brakes | Electric regenerative braking, hydraulic brakes with front dry discs and rear wet discs, hand lever parking brake |
| Wheels | Solid softy wheels, front 600×9, rear 700×12 |
| Steering | Power steering with hydrostatic orbitrol and hydraulic cylinder |
| Seats | Two suspension seats on slide adjusters |
| Equipment | |
| Lights | Dual headlights, dual tail/brake/reverse lights, turn signals |
| Indicators | Digital display, battery status, hour meter, Fault diagnostic |
| Accessories | 80V/12V converter for 12-volt accessories, horn, Clevis type hitch with safety spring |
| Safety | Deadman seat switch, reverse alarm |
Details
This compact two-seater is engineered for tight industrial settings requiring huge towing power. Its 50,000-lb.* payload is backed by a 40 hp AC direct-drive motor with constant laden speed and front suspension with dual shock absorbers. The dual planetary wheel drive with enclosed wet disks reduce maintenance; the electric regenerative brakes lengthen running time. It’s also virtually indestructible, thanks to the one-piece thick plate steel welded chassis reinforced at all high-stress areas.
- Equipment Type
- Industrial Tow Tractors / Industrial Vehicles
