41AM JLG

  • Long battery duty cycles and an automatic charger for more productivity
  • Most rigid mast in the industry for operator comfort and stability
  • Six-wheel design for improved maneuverability
  • Ground Entry Height: 1 ft 7 in. / 0.48 m
  • Machine Height: 8 ft 8 in. / 2.64 m
  • Machine Length: 4 ft 10 in. / 1.46 m
  • Machine Weight-AC: 1100 lb / 498.95 kg
  • Machine Weight-DC: 1230 lb / 557.92 kg
  • Machine Width: 2 ft 5 in. / 0.74 m
  • Outrigger Footprint Length: 6 ft 7 in. / 2.01 m
  • Outrigger Footprint Width: 6 ft 7 in. / 2.01 m
  • Outriggers or Stabilizers: Yes
  • Outriggers Up Max Lift Height: 41 ft / 12.44 m
  • Platform Capacity: 300 lb / 136.08 kg
  • Platform Dimension A: 2 ft 2 in. / 0.66 m
  • Platform Dimension B: 2 ft 2 in. / 0.65 m
  • Platform Height: 40 ft 9 in. / 12.42 m
  • Platform Height: 40 ft 9 in. / 12.42 m
  • Wheel Size – Front Caster: 6 x 2″
  • Wheel SIze – Rear: 10 x 2″
  • Working Height: 47 ft / 14.33 m
Details

The AM Series (AccessMaster®) push-around vertical lifts deliver a whole new level of value and performance. Available in six models, they’re an ideal choice for a low-cost solution to overhead work and maintenance applications. All AM and AMI Series are easy to transport, and you can change your platform-without any tools-in less than a minute, to suit your specific application needs.

Equipment Type
Aerial Lifts / Vertical Mast Lifts
