MC-480 Motrec

36V48V
Powertrain
MotorBrushless AC motor, 7.5 HP Intermittent, 10 HP MaxBrushless AC motor, 9 HP Intermittent, 15 HP Max
Drive AxleHelical gear differentialHelical gear differential
TransmissionDirect driveDirect drive
ControllerAC Electronic speed controllerAC Electronic speed controller
Energy
Voltage36V48V
BatterySix 6V-232AH batteriesEight 6V-232AH batteries
ChargerHigh-frequency (50/60HZ, 110/220VAC). Built-in & automatic.High frequency, built-in, automatic
Chassis
BodyAll-steel unibody constructionAll-steel unibody construction
SuspensionDual leaf springs on front and rearDual leaf springs on front and rear
BrakesRear hydraulic drum brakes, electromagnetic parking brake with manual hand releaseRear hydraulic drum brakes
Wheels5.7×8 LRD pneumatic tires5.7×8 LRD pneumatic tires
SteeringAutomotive steering wheelAutomotive steering wheel
SeatsTwo bucket seats on slide adjustersTwo bucket seats on slide adjusters
Equipment
LightsDual head lights, dual LED tail/brake lightsDual head lights, dual LED tail/brake lights
IndicatorsDigital battery status indicator with hour meter, speedometer & odometerDigital battery status indicator with hour meter, speedometer & odometer
AccessoriesBolt-on front bumper, DC/DC converter to equalize battery cells, HornBolt-on front bumper, DC/DC converter to equalize battery cells, Horn
SafetyDeadman seat switch, reverse alarm, hornDeadman seat switch, reverse alarm
Details

With its advanced engineering and improved modular design, the MC-480 takes productivity to new places. It boasts superior components throughout, including a high-efficiency AC powertrain and controller with multifunction display, direct drive differential and larger drum brakes. Its well-balanced rear-battery design increases maneuverability, traction and braking-even when carrying heavy loads. Standard features include bolt-on front bumper and all-steel unibody construction. A safe, rugged, do-it-all vehicle with unlimited configurations.

Equipment Type
Burden Carriers / Industrial Vehicles
