MP-500 Motrec

Back to Inventory

6 pass. 8 pass. 10 pass. 11 pass. 12 pass. Wheel
chair
Powertrain
Motor 15 hp 15 hp shunt motor motor 15 hp shunt motor motor 15 hp shunt motor motor 15 hp shunt motor motor 15 hp shunt motor motor
Drive Axle Differential with automotive ring gear Differential with automotive ring gear Differential with automotive ring gear Differential with automotive ring gear Differential with automotive ring gear Differential with automotive ring gear
Transmission Goodyear Eagle Synchronous drive Goodyear Eagle Synchronous drive Goodyear Eagle Synchronous drive Goodyear Eagle Synchronous drive Goodyear Eagle Synchronous drive Goodyear Eagle Synchronous drive
Controller Electronic speed controller Electronic speed controller Electronic speed controller Electronic speed controller Electronic speed controller Electronic speed controller
Energy
Voltage 48V 48V 48V 48V 48V
Battery Eight 6V-220AH batteries Eight 6V-244AH batteries Eight 6V-220AH batteries Eight 6V-220AH batteries Eight 6V-220AH batteries Eight 6V-244AH batteries
Charger 25 amp, built-in, automatic High-Frequency Charger, improves battery performance, prevents current surge, 50/60HZ, 110/220VAC High-Frequency Charger, improves battery performance, prevents current surge, 50/60HZ, 110/220VAC High-Frequency Charger, improves battery performance, prevents current surge, 50/60HZ, 110/220VAC High-Frequency Charger, improves battery performance, prevents current surge, 50/60HZ, 110/220VAC High-Frequency Charger, improves battery performance, prevents current surge, 50/60HZ, 110/220VAC
Chassis
Body 14-G diamond-plate steel body, tubular frame 14-G diamond-plate steel body, tubular frame 14-G diamond-plate steel body, tubular frame 14-G diamond-plate steel body, tubular frame 14-G diamond-plate steel body, tubular frame 14-G diamond-plate steel body, tubular frame
Suspension Dual leaf springs on front and rear Dual leaf springs on front and rear Dual leaf springs on front and rear Dual leaf springs on front and rear Dual leaf springs on front and rear Dual leaf springs on front and rear
Brakes Rear hydraulic brakes, 11 4 wheels 11 Rear hydraulic brakes, 11 Rear hydraulic brakes, 11 Rear hydraulic brakes, 11 4 wheels 11
Wheels 5.7×8 LRC pneumatic tires 5.7×8 LRC pneumatic tires 5.7×8 LRC pneumatic tires 5.7×8 LRC pneumatic tires 5.7×8 LRC pneumatic tires 5.7×8 LRC pneumatic tires
Steering Automotive steering wheel Automotive steering wheel Automotive steering wheel Automotive steering wheel Automotive steering wheel Automotive steering wheel
Seats Two bucket seats on slide adjusters Two bucket seats on slide adjusters, plus 3 bench type Two bucket seats on slide adjusters Two bucket seats on slide adjusters Two bucket seats on slide adjusters Two bucket seats on slide adjusters, plus 3 bench type and wheel chair access ramp
Equipment
Lights Dual head lights, dual tail/brake lights Dual head lights, dual tail/brake lights Dual head lights, dual tail/brake lights Dual head lights, dual tail/brake lights Dual head lights, dual tail/brake lights Dual head lights, dual tail/brake lights
Indicators Battery status indicator Battery status indicator Battery status indicator Battery status indicator Battery status indicator Battery status indicator
Accessories Horn Horn, Bolt-on Front Bumper, DC/DC converter to equalize battery cells Horn, Bolt-on Front Bumper Horn, Bolt-on Front Bumper Horn, Bolt-on Front Bumper Horn, Bolt-on Front Bumper, DC/DC converter to equalize battery cells
Safety Deadman seat switch Deadman seat switch, reverse alarm, seat belts Deadman seat switch, reverse alarm, seat belts Deadman seat switch Deadman seat switch Deadman seat switch, reverse alarm, seat belts
Details

This fully customizable vehicle is designed for moving large groups quickly, safely and comfortably. It can efficiently pull two tram trailers in all sorts of conditions and climb hills with ease. Its well-balanced design and short turning radius ensure superior maneuverability with responsive steering and braking. Its light-touch accelerator means a smoother ride, while it industrial batteries and cell equalization converter mean more trips per charge. Available in unlimited configurations, including forward-facing or back-to-back seating. Optional wheelchair ramp.

Equipment Type
Industrial Vehicles / Personnel Carriers
